Apple Pay Integration Guide

In this guide you will find the steps for a direct integration of Apple Pay. This payment method is also available via the SumUp Payment Widget and Swift Checkout SDK.

Offering Apple Pay requires registering with Apple on all web domains that will expose an Apple Pay button (includes TLD and subdomains). This is a requirement for production AND test environments.

Before you begin​

Here are the things that you need in order to complete the steps in this guide:

  • You have a merchant profile with SumUp and have already filled in your account details
  • For a test profile reach out to our support team through this contact form

Steps​

tip

The Apple Pay on the Web documentation describes their process of merchant validation which SumUp takes care of for you. The creation of an Apple Merchant ID or CSR, as described in their documentation is not required from you.

The below steps will get you started with Apple Pay:

  1. Host the domain association file at https://[YOUR_DOMAIN_NAME]/.well-known/apple-developer-merchantid-domain-association. Once hosted, request our integration specialists help finalize your connection to Apple Pay
  2. Before moving on to the next steps, get familiar with Apple’s requirements
  3. Create a checkout
  4. Create an Apple Payment request
const applePaymentRequest = {
  currencyCode: 'EUR',
  countryCode: 'DE',
  merchantCapabilities: ['supports3DS'],
  supportedNetworks: ['masterCard', 'visa'],
  total: {
    label: 'Demo',
    amount: '0.00',
    type: 'final',
  },
};
  1. Initiate an Apple Pay session and call the begin method
  2. Listen for the onvalidatemerchant callback and collect the validateUrl property. Create the following payload
{
  "target": "https://apple-pay-gateway-cert.apple.com/paymentservices/startSession",
  "context": "your_domain_name"
}

and initiate a merchant session by calling

PUT https://api.sumup.com/v0.1/checkouts/${checkoutId}/apple-pay-session

  1. The response from the previous step is needed to complete the merchant validation with the completeMerchantValidation method

  2. Submitting the payment dialog triggers the onpaymentauthorized callback, this is when you need to process the checkout. The process checkout request body needs to include a payment_type of apple_pay and an apple_pay object, containing the response from step 7

{
  "payment_type": "apple_pay",
  "id": "9be2da07-a7bd-4877-bc0a-e16cd909a876",
  "amount": 12,
  "currency": "EUR",
  "apple_pay": {
    "token": {
      "paymentData": {
        "data": "si2xuT2ArQo689SfE-long-token",
        "signature": "MIAGCSqGSIb3DQEHA-long-signature",
        "header": {
          "publicKeyHash": "PWfjDi3TSwgZ20TY/A7f3V6J/1rhHyRDCspbeljM0io=",
          "ephemeralPublicKey": "MFkwEwYHKoZIzj0CAQYIKoZIzj0DAQcDQgAEaBtz7UN2MNV0qInJVEEhXy10PU0KfO6KxFjXm93oKWL6lCsxZZGDl/EKioUHVSlKgpsKGin0xvgldfxeJVgy0g==",
          "transactionId": "62e0568bc9258e9d0e059d745650fc8211d05ef7a7a1589a6411bf9b12cdfd04"
        },
        "version": "EC_v1"
      },
      "paymentMethod": {
        "displayName": "MasterCard 8837",
        "network": "MasterCard",
        "type": "debit"
      },
      "transactionIdentifier": "62E0568BC9258E9D0E059D745650FC8211D05EF7A7A1589A6411BF9B12CDFD04"
    }
  }
}
note

Handling the responses from the API calls should be according to our public API contract & guidelines
